The ISL83070EIBZA-T from Renesas (Intersil) is a 3.3V 20Mbps RS-485/RS-422 transceiver with full/half-duplex support and hot-swap capability in SOIC-8.
| 包装 | SOIC-8 |
The ISL83070EIBZA-T from Renesas (Intersil) is a 3.3V 20Mbps RS-485/RS-422 transceiver with full/half-duplex support and hot-swap capability in SOIC-8.
The ISL83070EIBZA-T is a 3.3V RS-485/RS-422 half-duplex transceiver from Renesas (formerly Intersil) in SOIC-8, supporting data rates up to 20Mbps. The E suffix indicates enhanced ESD protection of +/-15kV HBM and +/-8kV IEC 61000-4-2 on the bus pins. The driver output differential voltage is 1.5V minimum into a 54-ohm load (standard RS-485 compliance). The receiver input impedance is 1/4 unit load (96k-ohm), allowing up to 128 devices on the bus. The fail-safe feature ensures RO is HIGH when the bus is open, shorted, or idle. The DE and RE pins have internal pull-down resistors, ensuring the device powers up in receive mode (DE=LOW, RE=LOW). The driver propagation delay is 8ns at 20Mbps, enabling high-speed communication. The supply current is 2.5mA active and 0.1uA in shutdown (when DE=LOW and RE=HIGH). The extended common-mode range of -7V to +12V on the bus pins allows operation in noisy industrial environments. The device includes thermal shutdown protection at 165C. The IBZA-T suffix specifies SOIC-8 with enhanced ESD, industrial temperature (-40C to +85C), tape-and-reel. The device is suitable for PROFIBUS, Modbus, and other RS-485-based industrial communication protocols.
| 针脚 | 名称 | 类型 | 功能 |
|---|---|---|---|
| 1 | RO | 输出 | Receiver output (to MCU UART RX, HIGH when A-B > 200mV) |
| 2 | RE | 输入 | Receiver enable (active LOW, internal pull-down) |
| 3 | 可选择丢弃 | 输入 | Driver enable (active HIGH, internal pull-down) |
| 4 | DI | 输入 | Driver data input (from MCU UART TX) |
| 5 | 接地 | 电源 | 地面 |
| 6 | A | 输入/输出 | Non-inverting bus pin |
| 7 | B | 输入/输出 | Inverting bus pin |
| 8 | VCC | 电源 | Supply (3.0-3.6V) |
| 制造商 | 部件编号 | 包装 | 说明 |
|---|---|---|---|
| 瑞萨 | ISL83070EIBZA-T | SOIC-8 | Same device, Renesas brand |
| 模拟器件公司 | ADM3485EARZ | SOIC-8 | 3.3V RS-485, 12Mbps, similar |
| 德州仪器 | SN65HVD72DR | SOIC-8 | 3.3V RS-485, 250kbps, similar |
| 马克西姆 | MAX3485ECSA+T | SOIC-8 | 3.3V RS-485, 10Mbps, ESD protected |
| 德州仪器 | THVD1500DR | SOIC-8 | 3.3V RS-485, 1Mbps, enhanced ESD |
